SAJ 16KW Three Phase Hybrid Inverter | SAJ H2 series

The H2-16K-LT2 16kW hybrid inverter delivers premium performance with 98.5% max efficiency. Supports up to 25.6kW of PV through 200% oversizing. Up to 10 parallel units allow for utility-scale expansion.
Brand: SAJ
Availability: In Stock
Rs. 625,000
SAJ 16 KW Hybrid Inverter | SAJ H2 series | A Grade Solar

SAJ H2-16K-LT2 Hybrid Solar Inverter – Specifications

General Information

  • Brand: SAJ

  • Model: H2-16K-LT2

  • Type: Hybrid Inverter / Charger

  • Output Type: Hybrid (On-Grid & Off-Grid)

Performance

  • Rated Output Power: 16,000 W (16kW)

  • Max PV Input Power: 25,600 W (25.6kW)

  • Max Efficiency: 98.5%

  • Euro Efficiency: 98.0%

  • Peak Off-Grid Power: 32,000 W (10 seconds)

  • Max AC Output Backup: 16,000 VA

Input Specifications

  • Battery Input Voltage: 40 – 60 V DC

  • PV Input Voltage Range: 160 – 950 V DC

  • MPPT Voltage Range: 160 – 950 V

Output Specifications

  • Output Voltage: 220/380 V, 230/400 V AC

  • Output Current:

    • Rated: 24.2 A

    • Maximum: 26.7 A

  • Output Frequency: 50 / 60 Hz

Battery Specifications

  • Max Battery Charging Current: 320 A

System Features

  • Max Parallel Units: 10 Inverters

  • Safety Standard: IEC / EN 62109-1 & 62109-2

Physical Details

  • Dimensions: 740 × 470 × 270 mm

  • Weight: 53 kg
