Phoenix Lithium Battery
Phoenix Lithium Battery – RLC-1.3-X1 LiFePO4 Battery
Model: RLC-1.3-X1
Battery Cell Chemistry: Lithium Iron Phosphate (LiFePO4)
Cell String: 1P4S
Nominal Voltage: 12.8 V
Battery Capacity: 105 Ah (25°C, 0.2C)
Nominal Energy: 1344 Wh
Operating Voltage Range: 10.4 V - 14.6 V
Charging Limited Voltage: 14.6 V
Charge Mode: CC/CV (0.5C to 14.6V, then 14.6V until charge current less than 0.02C)
Discharge Cut-off Voltage: 10.4 V
Recommended Charge / Discharge Current: 50 A
Max. Continuous Charge / Discharge Current: 75 A
Peak Charge / Discharge Current: 80 A @ 60s
Case Material: ABS
Dimensions (L x W x H): 260 x 167 x 210 mm (±3mm)
Weight: 12 Kg ± 1 Kg
Terminal Type: M8
