🔋 Battery Specifications
Battery Type:
LiFePO₄ (Lithium Iron Phosphate)
Energy Storage Capacity:
2560 Wh (2.56 kWh)
Rated Voltage:
25.6 V
Voltage Range:
21.6 V – 29.2 V
⚡ Performance
Maximum Charge Current:
100 A
Maximum Discharge Current:
100 A
Discharge Cut-Off Voltage:
21.6 V
Floating Voltage:
28.8 V
Cycle Life:
6000 cycles @ 80% Depth of Discharge (DOD)
🔌 Communication & Interface
Communication Ports:
RS485 / CAN
User Interface (HMI):
LCD Touchscreen + Status Lights + SOC Power Indicators
🌡️ Temperature & Environment
Working Temperature:
-20°C to 45°C
Charging Temperature:
0°C to 45°C
Discharging Temperature:
-20°C to 45°C
Storage Temperature:
-20°C to 30°C (up to 12 months)
30°C to 60°C (up to 6 months)
Humidity:
20% – 85% RH (Non-condensing)
🏗️ Physical Details
Weight:
Net Weight: 23.4 kg
Gross Weight: 25.8 kg
Installation Type:
Wall Mount / Floor Standing / Rack Mount
Cooling System:
Natural Cooling
Enclosure Protection:
IP21
✅ Certifications
Certifications:
IEC 62477, IEC 62619, IEC 60730, IEC 63056, IEC 61000, UN38.3
